CAD WX1600 UHF 100-Channel Frequency Agile Handheld Wireless System (G: 542 to 564 MHz)

UHF Frequency Band
40Hz to 15kHz Frequency Response
100-Channel Frequency Agile
Automatic Channel Configuration
SoftTouch On and Mute Switches
LED Indicators
2 AA Batteries Provide 15 Hours
1/4" and XLR Outputs on Receiver
Metal Chassis Receiver
*Includes Rack Ears

Details

The WX1600 UHF 100-Channel Frequency Agile Handheld Wireless System from CAD Audio is for capturing audio. It is used in various venues for vocal and speech applications such as for singers, public speakers, stage and theater performances and more. It features a frequency response of 40Hz to 15kHz and a dynamic range of 109dB. This handheld system features 100-channel UHF frequency agile reception and offers connectivity with a minimal of multipath interference.

The WX1600 is built with Scan-Link technology to provide instantaneous and automatic channel configuration. There is an automatic code encoded squelch to help prevent and eliminate unauthorized interference. AA batteries supply over 15 hours of battery life. The transmitters have SoftTouch On and Mute switches with multicolor LED indicators to monitor mute status and battery life. The receiver is built with a metal chassis to provide a durable and shielded enclosure. This receiver features 1/4" and XLR outputs to connect to a mixer source. Rack ears and joining kit are included.

Scan-Link Technology
Features instantaneous scan of the RF environment and automatic link to the transmitter and receiver

CADLock
Provides automatic tone encoded squelch to eliminate unauthorized interference

Two Frequency Bands
Two frequency bands provide more flexibility (Band G is 542 to 564 MHz and Band F is 638 to 662 MHz)

SoftTouch Switches
Features switches with multicolor LED indicators of on/mute and low battery

Long Battery Life
AA batteries provide over 15 hours battery life

Metal Chassis
Metal chassis receiver provides a durable shielded enclosure with included rack ears for mounting.

Band G: 542 - 564 MHz
Audio Frequency Response 40 Hz to 15 kHz
Dynamic Range >109 dB Outputs 1 x 1/4” (6.3 mm) 1 x XLRM
Handheld Transmitter Capsule Dynamic Cardioid
Frequency Response 40 Hz to 15 kHz
Transmit Power 10 mW
Batteries & Power 2 x AA batteries with >15 hours battery life

Serial Number: 21090053

This CAD item along with others are in stock at Allen Music. Thank you for giving us the opportunity to work for you.
